New Holland MHPLUS Mobile Excavator
Units
Dimensions
Boom/Stick Option (Mex) 1
A
Shipping Length Of Unit
27.66ft in
C
Shipping Height Of Unit
9.88ft in
I
Max Cutting Height
32.27ft in
J
Max Loading Height
23.3ft in
K
Max Reach Along Ground
29.01ft in
L
Max Vertical Wall Dig Depth
13.82ft in
M
Max Digging Depth
17.9ft in
Boom/Stick Option (Mex) 1
2pc boom / stick 2300mm
Boom/Stick Option (Mex) 2
A
Shipping Length Of Unit
27.7ft in
C
Shipping Height Of Unit
9.88ft in
I
Max Cutting Height
33.04ft in
J
Max Loading Height
24.07ft in
K
Max Reach Along Ground
29.96ft in
L
Max Vertical Wall Dig Depth
14.74ft in
M
Max Digging Depth
18.89ft in
Boom/Stick Option (Mex) 2
2pc boom / stick 2600mm
Boom/Stick Option (Mex) 3
C
Shipping Height Of Unit
9.88ft in
A
Shipping Length Of Unit
27.65ft in
I
Max Cutting Height
33.81ft in
J
Max Loading Height
24.84ft in
K
Max Reach Along Ground
30.93ft in
L
Max Vertical Wall Dig Depth
15.65ft in
M
Max Digging Depth
19.85ft in
Boom/Stick Option (Mex) 3
2pc boom / stick 2900mm
Dimensions
D
Wheelbase
8.37ft in
H
Tail Swing Radius
6.24ft in
B
Overall Width
8.34in
E
Ground Clearance
0.99ft in
F
Overall Width - Outriggers Down
12.8ft in
G
Height To Top Of Cab
9.88ft in
N
Upper Structure Clearance
4.01ft in
Specifications
Engine
Number Of Cylinders
6
Engine Model
CNH F4BE0684D
Net Power
133hp
Power Measured @
2000rpm
Displacement
360.1cu in
Aspiration
turbocharged with charge air cooling
Operational
Fuel Capacity
71.4gal
Operating Weight
40763.5lb
Cooling System Fluid Capacity
6.9gal
Engine Oil Capacity
4.3gal
Hydraulic System Fluid Capacity
37gal
Operational Voltage
24V
Alternator Supplied Amperage
70amps
Hydraulic System Relief Valve Pressure
5003.9psi
Hydraulic Pump Type
3 variable displacement, axial piston
Hydraulic Pump Flow Capacity
97.8gal/min
Oscillating Axle Angle
14degrees
Tire Size
10.00-20
Swing Mechanism
Swing Speed
9rpm
Swing Torque
30977.7lb ft
Transmission
Max Travel Speed
12.5mph
Drawbar Pull
20457.7lb
Buckets
Reference Bucket Capacity
0.7yd3
Minimum Bucket Capacity
0.4yd3
Maximum Bucket Capacity
1.1yd3
