Ranger H66DSG-II Skidder
Units
Dimensions
Dimensions
B
Overall Width
9.77ft in
C
Height To Top Of Cab
10.83ft in
I
Tong Opening At Tips
10.08in
Grapple Capacity - Tongs Tip To Tip
14ft2
Max Line Pull - Bare Drum
43750lb
Max Line Speed
269ft/min
Specifications
Engine
Number Of Cylinders
6
Engine Make
2301
Engine Model
Cummins 6A 5.9
Gross Power
174hp
Net Power
159hp
Peak Torque
447lb ft
Displacement
359cu in
Operational
Operating Weight
25530lb
Fuel Capacity
74gal
Cooling System Fluid Capacity
10gal
Engine Oil Capacity
3.6gal
Hydraulic System Fluid Capacity
14gal
Operational Voltage
24V
Alternator Supplied Amperage
70amps
Tire Size
28Lx26
Transmission
Transmission Type
Clark 32000
Number Of Forward Gears
3
Max Speed - Forward
13.6mph
Hydraulic
Pump Type
gear type
Pump Flow
36.8gal/min
Relief Valve Pressure
2750psi
