Snorkel TB50 Boom Lift
Units
Dimensions
Dimensions
A
Overall Length
25.27in
B
Overall Width
7.88ft in
C
Overall Height - Mast Lowered
7.88ft in
D
Wheelbase
7.88ft in
E
Ground Clearance
9.85in
Platform
F
Max Platform Height
50.53ft in
G
Max Horizontal Reach
39.05ft in
Max Platform Weight Capacity
500.45lb
Platform Inner Length
59.85in
Platform Inner Width
29.93in
Specifications
Engine
Fuel Type
gas/diesel
Operational
Operating Weight
12551lb
Fuel Capacity
20gal
Hydraulic System Fluid Capacity
25gal
Max Speed
3mph
Tire Size
12x16.5
Tire Fill/Type
pneumatic
