Sumitomo SH400-3 Hydraulic Excavator
Units
Dimensions
Boom/Stick Option (Hex) 1
A
Shipping Length Of Unit
39.18ft in
C
Shipping Height Of Unit
11.82ft in
I
Max Cutting Height
36.55ft in
J
Max Loading Height
25.4ft in
K
Max Reach Along Ground
39.38ft in
L
Max Vertical Wall Digging Depth
21.56ft in
M
Max Digging Depth
25.33ft in
Dimensions
E
Ground Clearance
1.78ft in
G
Height To Top Of Cab
11.82ft in
B
Width To Outside Of Tracks
11ft in
D
Length Of Track On Ground
13.29ft in
H
Tail Swing Radius
11.88ft in
Undercarriage
F
Track Gauge
9.03ft in
N
Shoe Size
23.63in
Max Travel Speed
3.3mph
Ground Pressure
11.75psi
Specifications
Engine
Engine Make
2353
Engine Model
AA-6SD1X
Net Power
320hp
Power Measured @
1950rpm
Displacement
600.5cu in
Operational
Operating Weight
96121.6lb
Fuel Capacity
161.2gal
Hydraulic System Fluid Capacity
118.9gal
Hydraulic System Relief Valve Pressure
4554.2psi
Swing Mechanism
Swing Speed
9rpm
Buckets
Reference Bucket Capacity
2.4yd3
