Tata Hitachi ZAXIS870LCH Hydraulic Excavator
Units
Dimensions
Boom/Stick Option (Hex) 1
I
Max Cutting Height
39.41ft in
J
Max Loading Height
26.68ft in
K
Max Reach Along Ground
39.44ft in
L
Max Vertical Wall Digging Depth
13.46ft in
M
Max Digging Depth
23.43ft in
Boom/Stick Option (Hex) 1
Boom 7100mm/Stick 2950mm
Boom/Stick Option (Hex) 2
I
Max Cutting Height
39.8ft in
J
Max Loading Height
26.84ft in
K
Max Reach Along Ground
41.05ft in
L
Max Vertical Wall Digging Depth
19.99ft in
M
Max Digging Depth
25.66ft in
Boom/Stick Option (Hex) 2
Boom 7100mm/Stick 3700mm
Boom/Stick Option (Hex) 3
I
Max Cutting Height
42.66ft in
J
Max Loading Height
29.79ft in
K
Max Reach Along Ground
45.35ft in
L
Max Vertical Wall Digging Depth
22.45ft in
M
Max Digging Depth
29.11ft in
Boom/Stick Option (Hex) 3
Boom 8400mm/Stick 3700mm
Dimensions
E
Ground Clearance
2.92ft in
G
Height To Top Of Cab
12.41ft in
B
Width To Outside Of Tracks
13.46ft in
D
Length Of Track On Ground
16.77ft in
H
Tail Swing Radius
15.1ft in
Removal Counterweight Clearance
5.52ft in
Undercarriage
F
Track Gauge
11.32ft in
N
Shoe Size
25.6in
Max Travel Speed
2.55mph
Number Of Shoes Per Side
51
Number Of Carrier Rollers Per Side
3
Number Of Track Rollers Per Side
9
Ground Pressure
17.55psi
Specifications
Engine
Number Of Cylinders
6
Engine Make
2353
Engine Model
AH-6WG1XYSA-03
Net Power
532.4hp
Power Measured @
1800rpm
Max Torque
1659.6lb ft
Displacement
957cu in
Aspiration
turbocharged
Torque Measured @
1600rpm
Operational
Operating Weight
185188.4lb
Fuel Capacity
295.9gal
Cooling System Fluid Capacity
30.7gal
Hydraulic System Fluid Capacity
208.7gal
Operating Voltage
24V
Engine Oil Capacity
15.1gal
Swing Drive Fluid Capacity
4gal
Alternator Supplied Amperage
50amps
Hydraulic System Relief Valve Pressure
4974.8psi
Hydraulic Pump Flow Capacity
279gal/min
Swing Mechanism
Swing Speed
7.3rpm
Buckets
Reference Bucket Capacity
4.6yd3
Minimum Bucket Capacity
2.5yd3
Maximum Bucket Capacity
5.7yd3
