Terex RH170 Shovel
Units
Dimensions
Backhoe Boom / Stick 1
M
Max Dig Depth
22.97ft in
Q
Max Cutting Height
55.78ft in
Backhoe Boom / Stick
Boom 31\'2\" (9500mm)/Stick 14\\\\\\\\\\\\\\\'9\\\\\\\\\\\\\\\" (4500mm)
Dimensions
B
Width Over Tracks
21.66ft in
D
Length Of Track On Ground
20.35ft in
G
Height To Top Of Cab
26.74ft in
E
Ground Clearance
38.59in
Upper Structure Ground Clearance
8.4ft in
Length Of Tracks
26.48ft in
Height Of Tracks
7.22ft in
Loading Shovel
S
Max Dig Reach
50.2ft in
R
Max Dump Height
35.44ft in
Q
Max Cutting Height
46.59ft in
T
Max Dig Depth
8.21ft in
P
Height To Top Of Boom - Shovel
26.91ft in
Loading Shovel
Boom 7.3m (23\'11\") stick 4.6m (15\'1\'\')
Arm Crowd Force
1650lb ft
Undercarriage
H
Tail Swing Radius
22.25ft in
F
Track Gauge
17.72ft in
Backhoe Ground Pressure - Shoe 1
34.1psi
Backhoe Operating Weight - Shoe 1
869503.11lb
Backhoe Shoe Width 1
47.25in
Max Travel Speed
1.62mph
Number Of Lower Rollers
7
Number Of Track Shoes Per Side
42
Number Of Upper Rollers
2
Specifications
Engine
Number Of Cylinders
24
Engine Make
2347
Engine Model
2x KTA 38 C-1200
Net Power
2000hp
Gross Power
2400hp
Power Measured @
1750rpm
Displacement
2306.7cu in
Aspiration
turbocharged and air to air aftercooled
Operational
Fuel Capacity
1664.3gal
Hydraulic System Fluid Capacity
792.6gal
Swing Speed
4.7rpm
Operating Voltage
24V
Alternator Supplied Amperage
350amps
Buckets
Reference Bucket Capacity
27.5yd3
Minimum Bucket Capacity
23.6yd3
Maximum Bucket Capacity
27.5yd3
