Terex TXC420LC-1 Hydraulic Excavator
Units
Dimensions
Boom/Stick Option (Hex) 1
A
Shipping Length Of Unit
38.36ft in
C
Shipping Height Of Unit
11.73ft in
I
Max Cutting Height
36.09ft in
J
Max Loading Height
25.74ft in
K
Max Reach Along Ground
37.11ft in
L
Max Vertical Wall Digging Depth
14.44ft in
M
Max Digging Depth
25.35ft in
Boom/Stick Option (Hex) 1
22'4'' (6700mm) boom w/ stick 10'8'' (3250mm)
Boom/Stick Option (Hex) 2
I
Max Cutting Height
37.72ft in
J
Max Loading Height
27.33ft in
K
Max Reach Along Ground
39.6ft in
L
Max Vertical Wall Digging Depth
16.62ft in
M
Max Digging Depth
27.79ft in
Boom/Stick Option (Hex) 2
22'4'' (6700mm) boom w/ stick 13'1'' (4000mm)
Dimensions
E
Ground Clearance
1.78ft in
G
Height To Top Of Cab
10.34ft in
B
Width To Outside Of Tracks
11ft in
D
Length Of Track On Ground
13.95ft in
H
Tail Swing Radius
12.01ft in
Removal Counterweight Clearance
4.19ft in
Undercarriage
F
Track Gauge
9.03ft in
N
Shoe Size
23.63in
Max Travel Speed
3.42mph
Number Of Shoes Per Side
50
Number Of Track Rollers Per Side
9
Ground Pressure
10.4psi
Number Of Carrier Rollers Per Side
2
Specifications
Engine
Number Of Cylinders
6
Engine Make
2253
Engine Model
DE12TIS
Net Power
281hp
Power Measured @
2000rpm
Max Torque
853lb ft
Displacement
675cu in
Aspiration
Turbocharged air to air intercooled
Torque Measured @
1400rpm
Operational
Operating Weight
90830lb
Fuel Capacity
145.3gal
Cooling System Fluid Capacity
14.8gal
Hydraulic System Fluid Capacity
108.4gal
Operating Voltage
24V
Engine Oil Capacity
7.4gal
Swing Drive Fluid Capacity
1.6gal
Hydraulic System Relief Valve Pressure
4550psi
Hydraulic Pump Flow Capacity
166.5gal/min
Swing Mechanism
Swing Speed
9.5rpm
Buckets
Reference Bucket Capacity
2.5yd3
Minimum Bucket Capacity
1.9yd3
Maximum Bucket Capacity
2.9yd3
