Tong Yang Moolsan T433 NC 4WD Tractor
Units
Dimensions
Dimensions
A
Overall Length
11.78in
B
Width Outside Frame
5.22ft in
C
Height To Top Of Cab
8.5ft in
D
Wheelbase
6.35in
Tire Size
front 12-16.5R4 rear 17.5L-24R4
Specifications
Engine
Number Of Cylinders
4
Engine Make
2236
Engine Model
C2.2
Gross Power
42.7hp
Pto Power
32.8hp
Power Measured @
2600rpm
Displacement
135.2cu in
Operational
Fuel Capacity
15.9gal
Operating Weight
4188.8lb
Hydraulic System Fluid Capacity
9.3gal
Engine Oil Capacity
2.2gal
Cooling System Fluid Capacity
2.3gal
3 Point Hitch Type
Cat I
Turning Radius
11ft in
3 Point Hitch Lift Capacity @ 24 Inches
2105.5lb
Operating Voltage
12V
Alternator Supplied Amperage
65amps
Transmission
Transmission Type
sync/shuttle
Number Of Forward Gears
16
Number Of Reverse Gears
16
Max Speed
19.7mph
Hydraulic System
Pump Flow Capacity
13.5gal/min
Number Of Remote Control Valves
2
