Ursus 2812 Utility Tractor
Units
Dimensions
Dimensions
A
Overall Length
10.52in
D
Wheelbase
6.34ft in
B
Overall Width
5.98ft in
Height With Rops
7.75ft in
Specifications
Engine
Number Of Cylinders
3
Engine Make
2441
Engine Model
3250
Gross Power
40hp
Pto Power
34hp
Power Measured @
2000rpm
Max Torque
111.4lb ft
Torque Measured @
1400rpm
Displacement
152.7cu in
Operational
Operating Weight
4795.1lb
Fuel Capacity
15.4gal
Engine Oil Capacity
1.8gal
Cooling System Fluid Capacity
2.6gal
Hydraulic System Fluid Capacity
8.5gal
3 Point Hitch Lift Capacity @ 24 Inches
2932.2lb
Tire Size Front - 2wd / 4wd
6.00-16 6PR
Rear Tires Size 2wd/4wd
12.4R8
Operating Voltage
12V
Alternator Supplied Amperage
44amps
Transmission
Transmission Type
mechanical with sliding gears
Number Of Forward Gears
8
Number Of Reverse Gears
2
Max Speed
15.1mph
Hydraulic System
Relief Valve Setting
2320.7psi
Pump Flow Capacity
4gal/min
