Volvo BM A20 6x4 Articulated Dump Truck
Units
Dimensions
Dimensions
A
Overall Length
32.96ft in
B
Overall Width
8.18ft in
C
Overall Height
10.17ft in
D
Wheelbase
14.18ft in
E
Ground Clearance
1.31ft in
F
Dump Height
20.84ft in
G
Dump Ground Clearance
1.97ft in
Dump
H
Dump Angle
63degrees
Lower Time
16sec
Rated Payload
40785.52lb
Capacity - Struck
11.38yd3
Raise Time
16sec
Capacity - Heaped
14.39yd3
Specifications
Engine
Number Of Cylinders
6
Engine Make
2244
Engine Model
TD 71G
Gross Power
201hp
Net Power
186hp
Power Measured @
2200rpm
Max Torque
472.1lb ft
Torque Measured @
1700rpm
Aspiration
turbocharged
Displacement
410.7cu in
Operational
Fuel Capacity
78gal
Hydraulic System Fluid Capacity
45gal
Cooling System Fluid Capacity
6.4gal
Engine Oil Capacity
6.4gal
Transmission Fluid Capacity
5.6gal
Operating Voltage
24V
Tire Size
Front - 18.00 R 25* / Rear 20.5 R 25*
Transmission
Transmission Type
Automatic Power-Shift
Number Of Forward Gears
4
Number Of Reverse Gears
3
Max Speed
21.2mph
Weights
Front Axle - Empty
17200lb
Rear Axle - Empty
15550lb
Front Axle - Loaded
23150%
Rear Axle - Loaded
50380lb
Total Empty
32750lb
Total Loaded
73540lb
