Volvo EC210NLC Hydraulic Excavator
Dimensions
Boom/Stick Option (Hex) 1
Shipping Length Of Unit
32.19ft in
Shipping Height Of Unit
10.34ft in
Max Cutting Height
28.97ft in
Max Loading Height
20.05ft in
Max Reach Along Ground
28.68ft in
Max Vertical Wall Digging Depth
13.88ft in
Max Digging Depth
18.48ft in
Boom/Stick Option (Hex) 1
Monobloc Boom 5700mm / Stick 1800mm
Boom/Stick Option (Hex) 2
Shipping Length Of Unit
31.99ft in
Max Cutting Height
30.29ft in
Shipping Height Of Unit
10.24ft in
Max Loading Height
21.04ft in
Max Reach Along Ground
30.29ft in
Max Vertical Wall Digging Depth
17.62ft in
Max Digging Depth
20.12ft in
Boom/Stick Option (Hex) 2
Monobloc Boom 5700mm / Stick 2300mm
Boom/Stick Option (Hex) 3
Shipping Length Of Unit
31.73ft in
Max Cutting Height
31.57ft in
Max Loading Height
22.41ft in
Shipping Height Of Unit
11.78ft in
Max Reach Along Ground
34.81ft in
Max Vertical Wall Digging Depth
21.56ft in
Max Digging Depth
25.37ft in
Boom/Stick Option (Hex) 3
Monobloc Boom 5700mm / Stick 3900mm
Boom/Stick Option (Hex) 4
Shipping Length Of Unit
31.73ft in
Shipping Height Of Unit
9.98ft in
Max Cutting Height
32.49ft in
Max Loading Height
23ft in
Max Reach Along Ground
28.35ft in
Max Digging Depth
17.13ft in
Boom/Stick Option (Hex) 4
2-piece Boom 5570mm / Stick 1800mm
Max Vertical Wall Dig Depth
13.1ft in
Boom/Stick Option (Hex) 5
Shipping Length Of Unit
31.53ft in
Shipping Height Of Unit
9.98ft in
Max Cutting Height
33.9ft in
Max Loading Height
24.28ft in
Max Reach Along Ground
29.96ft in
Max Digging Depth
18.77ft in
Max Vertical Wall Dig Depth
15.65ft in
Boom/Stick Option (Hex) 5
2-piece Boom 5570mm / Stick 2300mm
Boom/Stick Option (Hex) 6
Max Cutting Height
36.68ft in
Max Loading Height
27.14ft in
Shipping Length Of Unit
31.07ft in
Max Reach Along Ground
34.55ft in
Shipping Height Of Unit
11.91ft in
Max Digging Depth
23.76ft in
Max Vertical Wall Dig Depth
20.28ft in
Boom/Stick Option (Hex) 6
2-piece Boom 5570mm / Stick 3900mm
Dimensions
Ground Clearance
1.51ft in
Height To Top Of Cab
9.52ft in
Width To Outside Of Tracks
9.45ft in
Length Of Track On Ground
11.06ft in
Tail Swing Radius
9.36ft in
Removal Counterweight Clearance
3.37ft in
Undercarriage
Track Gauge
7.22ft in
Shoe Size
23.63in
Number Of Carrier Rollers Per Side
2
Number Of Shoes Per Side
46
Number Of Track Rollers Per Side
7
Max Travel Speed
3.42mph
Specifications
Engine
Number Of Cylinders
6
Engine Make
2347
Engine Model
B5.9-C
Gross Power
160hp
Net Power
143hp
Power Measured @
1900rpm
Max Torque
455.9lb ft
Displacement
360.1cu in
Aspiration
Turbocharged
Torque Measured @
1500rpm
Operational
Operating Weight
43872lb
Fuel Capacity
92.5gal
Cooling System Fluid Capacity
7.1gal
Hydraulic System Fluid Capacity
75.3gal
Operating Voltage
24V
Engine Oil Capacity
6.4gal
Swing Drive Fluid Capacity
1.6gal
Alternator Supplied Amperage
50amps
Hydraulic System Relief Valve Pressure
4974.8psi
Hydraulic Pump Flow Capacity
105.7gal/min
Swing Mechanism
Swing Speed
11.6rpm
Buckets
Reference Bucket Capacity
0.7yd3
Minimum Bucket Capacity
0.7yd3
Maximum Bucket Capacity
1.7yd3
