Volvo G726 VHP Motor Grader
Units
Dimensions
Dimensions
A
Overall Length
27.84ft in
B
Width Over Tires
8.34ft in
D
Wheelbase
20ft in
H
Blade Base
8.51ft in
Height To Top Of Isomount Cab
10.17ft in
Specifications
Engine
Number Of Cylinders
6
Engine Make
2347
Engine Model
6C8.3
Max Power
195hp
Net Power Gears 7-8
195hp
Net Torque Gears 7-8
636lb ft
Displacement
504.5cu in
Aspiration
turbocharged
Operational
Std Operation Weight - Front Axle
10007lb
Hydraulic System Fluid Capacity
23.8gal
Std Operation Weight - Rear Axle
23543lb
Std Operation Weight - Total
33550lb
Fuel Capacity
100gal
Cooling System Fluid Capacity
12.5gal
Transmission Fluid Capacity
10.1gal
Rear Diff/Final Drive Fluid Capacity
6.1gal
Tandem Case Fluid Capacity (Each)
26.5gal
Tire Size
14.00 x 24, G-2
Operating Voltage
12V
Alternator Supplied Amperage
75amps
Steering
Articulation Angle
22degrees
Transmission
Transmission Type
Powershift
Number Of Gears - Forward
8
Number Of Gears - Reverse
4
Max Speed - Forward
28.5mph
Max Speed - Reverse
20.4mph
Front Axle
Wheel Lean
15degrees
Oscillation - Total
16degrees
Ground Clearance
2.1ft in
Moldboard
Moldboard Width
12ft in
Moldboard Height
25in
Moldboard Thickness
0.9in
Max Depth Of Cut
32in
Side Shift Left
26.5in
Side Shift Right
26.5in
Blade Pull At Max Weight
21189lb
Blade Down Pressure
17403lb
Hydraulic System
Pump Type
load sensing hydraulic
Pump Flow
50.5gal/min
Relief Valve Pressure
2500psi
Circle
Diameter
66.3in
Rotation
360degrees
Shift Left
30.5in
Shift Right
29.5in
Max Reach Outside Tires - Left
79.5in
Max Reach Outside Tires - Right
79in
Max Lift Above Ground
17.5in
Blade Tip Angle - Front
44degrees
Blade Tip Angle - Rear
6.5degrees
