Yale GLP 20 SVX Forklift

Forklift
Forklift
Forklift
Forklift
Forklift
Forklift
Units

Dimensions

Dimensions

A

Length To Fork Face

7.45ft in

B

Overall Width

3.51ft in

C

Overall Height - Mast Lowered

7.14ft in

D

Wheelbase

4.55ft in

E

Ground Clearance

4.34in

F

Height To Top Of Overhead Guard

7.06ft in

G

Max Fork Height

10.8ft in

Turning Radius

6.52ft in

Mast

H

Mast Tip Forward

6degrees

I

Mast Tip Rear

5degrees

Lower Speed

100.4ft/min

Load Capacity

4409.25lb

Load Center

19.69in

Lift Speed

112.21ft/min


Specifications

Engine

Number Of Cylinders

4

Engine Make

2357

Engine Model

FE

Power

40hp

Torque

81.9lb ft

Power Measured @

2600rpm

Displacement

122cu in

Torque Measured @

2400rpm

Fuel Type

LPG

Operational

Operating Weight

7262.1lb

Tire Type

Supercushion

Number Of Front Wheels

2

Number Of Rear Wheels

2

Max Speed

12.8mph
