Belle 761 Skid Steer Loader

Skid Steer Loader
Skid Steer Loader
Skid Steer Loader
Skid Steer Loader
Skid Steer Loader
Skid Steer Loader
Units

Dimensions

Dimensions

A

Length With Bucket

9.93ft in

B

Width Over Tires

4.84ft in

E

Ground Clearance

10in

C

Height To Top Of Cab

6.43ft in

D

Wheelbase

2.92ft in

F

Length W/O Bucket

7.87ft in

G

Clearance At Max Lift And Dump

7.47ft in

H

Reach At Max Lift And Dump

21.26in

Turning Radius From Center - Machine Rear

43.63in

Turning Radius From Center - Inc Bucket

69.73in


Specifications

Engine

Number Of Cylinders

4

Engine Make

2351

Engine Model

104-22

Net Power

48hp

Power Measured @

2600rpm

Aspiration

Natural

Displacement

135.3cu in

Operational

Operational Weight

4987lb

Fuel Capacity

13.8gal

Hydraulic System Fluid Capacity

14.6gal

Tire Size

10x 16.5

Loader

Breakout Force

3616lb

Operating Load Rating

1378lb

Tipping Angle

2756degrees

Bucket Capacity

0.5yd3

Hydraulic

Pump Flow Capacity

15.9gal/min

Relief Valve Pressure

2842psi
