Caterpillar 225SA Hydraulic Excavator
Units
Dimensions
Boom/Stick Option (Hex) 1
A
Shipping Length Of Unit
36.17ft in
C
Shipping Height Of Unit
11.84ft in
I
Max Cutting Height
30.84ft in
J
Max Loading Height
21.95ft in
K
Max Reach Along Ground
35.21ft in
L
Max Vertical Wall Digging Depth
15ft in
M
Max Digging Depth
23.99ft in
Boom/Stick Option (Hex) 1
one piece boom w/ stick 2440mm
Boom/Stick Option (Hex) 2
A
Shipping Length Of Unit
36.01ft in
I
Max Cutting Height
31.5ft in
C
Shipping Height Of Unit
12.26ft in
J
Max Loading Height
22.68ft in
K
Max Reach Along Ground
37.08ft in
L
Max Vertical Wall Digging Depth
15.88ft in
M
Max Digging Depth
25.99ft in
Boom/Stick Option (Hex) 2
one piece boom w/ stick 3050mm
Dimensions
E
Ground Clearance
1.9ft in
G
Height To Top Of Cab
11.09ft in
B
Width To Outside Of Tracks
11.34ft in
H
Tail Swing Radius
9.59ft in
Removal Counterweight Clearance
4.09ft in
Undercarriage
F
Track Gauge
8.67ft in
N
Shoe Size
32in
Drawbar Pull
52790lb
Max Travel Speed
1.8mph
Ground Pressure
7.1psi
Specifications
Engine
Number Of Cylinders
8
Engine Make
2236
Engine Model
3208
Net Power
180hp
Power Measured @
2200rpm
Displacement
634.7cu in
Aspiration
turbocharged
Operational
Operating Weight
68905.5lb
Fuel Capacity
65gal
Cooling System Fluid Capacity
10.1gal
Hydraulic System Fluid Capacity
151.9gal
Engine Oil Capacity
3.3gal
Operating Voltage
24V
Swing Drive Fluid Capacity
7.6gal
Alternator Supplied Amperage
35amps
Hydraulic System Relief Valve Pressure
4500psi
Hydraulic Pump Flow Capacity
121gal/min
Swing Mechanism
Swing Torque
54756.7lb ft
Buckets
Reference Bucket Capacity
1.3yd3
Minimum Bucket Capacity
0.8yd3
Maximum Bucket Capacity
1.4yd3
