Caterpillar 247B Series 3 Multi Terrain Loader
Units
Dimensions
Dimensions
B
Width Over Tracks
5.5ft in
C
Height To Top Of Cab
6.53ft in
E
Ground Clearance
10in
G
Clearance At Max Lift And Dump
7.01ft in
H
Reach At Max Lift And Dump
2.06ft in
Length - Track On Ground
59in
Length - With Bucket On Ground
129in
Length - Without Bucket
99in
Length With Out Bucket
8.27ft in
Bucket Pin Height - Maximum Lift
9.34ft in
Clearance At Maximum Lift And Dump
84in
Departure Angle
41 degrees
Height - Top Of Cab
6.5ft in
Turning Radius From Center - Inc Bucket
82.49in
Turning Radius From Center - Machine Rear
54.22in
Vehicle Width
66in
Length With Bucket
10.78ft in
Bucket Pin Height - Carry Position
8.7in
Maximum Dump Angle
40 degrees
Maximum Overall Height
150in
Maximum Reach - With Arms Parallel
53in
Overall Length - Track
75in
Rack Back Angle - Maximum Height
82 degrees
Reach At Maximum Lift/Dump
25in
Turn Radius From Center - Bucket
82in
Turn Radius From Center - Coupler
52in
Turn Radius From Center - Rear
54in
Undercarriage
D
Length Of Track On Ground
4.92ft in
Ground Contact Area
1770in2
Ground Pressure
4psi
Specifications
Engine
Engine Make
2236
Engine Model
C2.2T
Gross Power
62hp
Net Power
56hp
Displacement
134cu in
Bore
3.3in
Stroke
3.9in
Gross Power - Sae J1995
62hp
Engine Model
Cat C2.2 T
Net Power - Iso 9249 Eec
56hp
Net Power - Sae 1349
56hp
Operational
Operating Weight
6997lb
Cooling System Fluid Capacity
2.7gal
Fuel Capacity
17.2gal
Engine Oil Capacity
2.7gal
Hydraulic System Fluid Capacity
14.6gal
Operating Voltage
12V
Alternator Supplied Amperage
85amps
Max Speed - Low Range
7mph
Power Train
Travel Speed Forward
7mph
Travel Speed Reverse
7mph
Loader
Breakout Force
4060lb
Operating Load
2149.6lb
Tipping Angle
4299.1degrees
Weights
Operating Weight
6997lb
Hydraulic
Pump Flow
16.2gal/min
Relief Valve Pressure
3335psi
Hydraulic System
Hydraulic Power
31hp
Loader Hydraulic Pressure
3335 psi
Loader Hydraulic Flow
16 gal/min
Hydraulic Flow
Standard
Operating Specifications
Rated Operating Capacities - 50% Tipping Load
2150lb
Rated Operating Capacities - 35% Tipping Load
1505lb
Ground Contact Area
1770in2
Ground Pressure
4 psi
Tipping Load
4300lb
Breakout Force - Tilt Cylinder
4060lb
Service Refill Capacities
Cooling System
2.6gal
Fuel Tank
17gal
Hydraulic Tank
9.2gal
Engine Crankcase
2.6gal
Hydraulic System
14.5gal
Cab
Rops
SAE J1040 MAY94, ISO 3471:1994
Fops
SAE J1043 SEPT87, ISO 3449:1992 Level I
Fops Level Ii
SAE J231 JAN81, ISO 3449:1992 Level II
