Caterpillar AD55 Articulated Dump Truck
Units
Dimensions
Dimensions
A
Overall Length
37.89ft in
B
Overall Width
10.98ft in
C
Overall Height
16.41ft in
D
Wheelbase
19.36ft in
E
Ground Clearance
1.29ft in
Dump
Lower Time
4sec
Raise Time
11sec
Capacity - Struck
35.19yd3
Specifications
Engine
Engine Make
2236
Engine Model
C18 ATTAAC
Gross Power
650hp
Net Power
617hp
Power Measured @
2000rpm
Displacement
1106.5cu in
Operational
Fuel Capacity
201.9gal
Hydraulic System Fluid Capacity
70.3gal
Cooling System Fluid Capacity
22.5gal
Engine Oil Capacity
17gal
Transmission Fluid Capacity
15.9gal
Tire Size
25x65 R33
Transmission
Number Of Forward Gears
7
Number Of Reverse Gears
2
Max Speed
26.9mph
Weights
Front Axle - Empty
69004lb
Rear Axle - Empty
34612lb
Total Empty
103617lb
