Caterpillar D11T CD Crawler Tractor
Units
Dimensions
Dimensions
A
Length W/ Blade
35.83ft in
B
Width Over Tracks
12.49ft in
C
Height To Top Of Cab
15.33ft in
D
Length Of Track On Ground
14.59ft in
E
Ground Clearance
2.05ft in
F
Length W/O Blade
19.75ft in
Undercarriage
G
Track Gauge
9.51ft in
H
Standard Shoe Size
35.83in
Number Of Shoes Per Side
41
Ground Contact Area
12581in2
Track Pitch
12.5in
Specifications
Engine
Number Of Cylinders
12
Engine Make
2236
Engine Model
C32 ACERT
Gross Power
935hp
Net Power
850hp
Power Measured @
1800rpm
Displacement
1959cu in
Aspiration
Turbocharged
Operational
Operating Weight
248600lb
Fuel Capacity
426gal
Cooling System Fluid Capacity
238.8gal
Engine Oil Capacity
106gal
Hydraulic Fluid Capacity
64.2gal
Powertrain Fluid Capacity
91gal
Final Drives Fluid Capacity
8gal
Operating Voltage
24V
Alternator Supplied Amperage
100amps
Transmission
Transmission Type
Powershift
Number Of Forward Gears
3
Number Of Reverse Gears
3
Max Speed - Forward
7.3mph
Max Speed - Reverse
8.7mph
Hydraulic System
Pump Type
gear driven
Relief Valve Pressure
3500psi
Pump Flow Capacity
66gal/min
Standard Blade
Width
22ft in
Height
108in
Capacity
57yd3
Cutting Depth
67.2in
