Komatsu D475A-5SD Crawler Tractor
Units
Dimensions
Dimensions
A
Length W/ Blade
34.54ft in
B
Width Over Tracks
9.08ft in
C
Height To Top Of Cab
15.08ft in
Undercarriage
H
Standard Shoe Size
32in
Ground Pressure
16.11psi
Number Of Shoes Per Side
40
Number Of Track Rollers Per Side
7
Ground Contact Area
10960in2
Specifications
Engine
Number Of Cylinders
12
Engine Make
2238
Engine Model
SDA12V140E
Net Power
860hp
Displacement
1860cu in
Aspiration
turbocharged, aftercooled
Operational
Operating Weight
238270lb
Fuel Capacity
441gal
Cooling System Fluid Capacity
72.6gal
Engine Oil Capacity
32gal
Final Drives Fluid Capacity
19.8gal
Transmission
Transmission Type
Komatsu TORQFLOW transmission
Number Of Forward Gears
3
Number Of Reverse Gears
3
Max Speed - Forward
6.8mph
Max Speed - Reverse
8.9mph
Hydraulic System
Pump Type
plunger type hydraulic pump
Relief Valve Pressure
3980psi
Pump Flow Capacity
143gal/min
Standard Blade
Width
21.3ft in
Height
10.6in
Cutting Depth
2.9in
