Caterpillar D5K LGP Crawler Tractor
Units
Dimensions
Dimensions
B
Width Over Tracks
7.91ft in
C
Height To Top Of Cab
8.93ft in
D
Length Of Track On Ground
7.58ft in
E
Ground Clearance
1.08ft in
F
Length W/O Blade
10.71ft in
Undercarriage
G
Track Gauge
5.75ft in
H
Standard Shoe Size
26in
Ground Contact Area
4726in2
Number Of Track Rollers Per Side
7
Number Of Shoes Per Side
40
Ground Pressure
4.52psi
Specifications
Engine
Engine Make
2236
Engine Model
C4.4 ACERT
Gross Power
100hp
Net Power
96hp
Displacement
269cu in
Operational
Operating Weight
21347lb
Fuel Capacity
51.5gal
Cooling System Fluid Capacity
6gal
Engine Oil Capacity
3gal
Hydraulic Fluid Capacity
15.7gal
Final Drives Fluid Capacity
2.6gal
Operating Voltage
12V
Alternator Supplied Amperage
120amps
Transmission
Transmission Type
Hydrostatic
Max Speed - Forward
5.6mph
Max Speed - Reverse
6.2mph
Hydraulic System
Relief Valve Pressure
2988psi
Pump Flow Capacity
19.4gal/min
Standard Blade
Width
10.6ft in
Height
39.8in
Capacity
3.1yd3
Blade Angle (Both Directions)
25degrees
Cutting Depth
22.5in
