Daewoo DSL802 Skid Steer Loader
Units
Dimensions
Dimensions
A
Length With Bucket
10.43ft in
B
Width Over Tires
5.46ft in
E
Ground Clearance
8.59in
C
Height To Top Of Cab
6.62ft in
D
Wheelbase
3.49ft in
F
Length W/O Bucket
8.23ft in
G
Clearance At Max Lift And Dump
7.63ft in
H
Reach At Max Lift And Dump
22.52in
Turning Radius From Center - Machine Rear
62.72in
Turning Radius From Center - Inc Bucket
74.14in
Specifications
Engine
Number Of Cylinders
4
Engine Make
2253
Engine Model
D430
Gross Power
64hp
Power Measured @
2500rpm
Displacement
181.7cu in
Operational
Operational Weight
6594.1lb
Fuel Capacity
21.2gal
Max Speed
6.8mph
Tire Size
12 x 16.5
Loader
Breakout Force
5467.5lb
Operating Load Rating
1699.8lb
Tipping Angle
3593.6degrees
Bucket Capacity
0.5yd3
Hydraulic
Pump Flow Capacity
20.6gal/min
