Doosan DX530LC-5 Hydraulic Excavator
Units
Dimensions
Boom/Stick Option (Hex) 1
A
Shipping Length Of Unit
40.13ft in
C
Shipping Height Of Unit
12.47ft in
J
Max Loading Height
25.35ft in
K
Max Reach Along Ground
37.59ft in
L
Max Vertical Wall Digging Depth
13.28ft in
M
Max Digging Depth
24.09ft in
Boom/Stick Option (Hex) 1
Boom 23\'4\" (7100mm)/Arm 9\'6\"(2900mm)
Min Digging Reach
6.6ft in
Minimum Swing Radius
206.11in
Boom/Stick Option (Hex) 2
A
Shipping Length Of Unit
40.13ft in
C
Shipping Height Of Unit
11.75ft in
J
Max Loading Height
25.82ft in
L
Max Vertical Wall Digging Depth
14.34ft in
M
Max Digging Depth
25.56ft in
Minimum Swing Radius
205.12in
Maximum Reach At Ground Level
467.13in
Min Digging Reach
2.76ft in
Boom/Stick Option (Hex) 2
Boom 23\'4\" (7100mm)/Arm 11\"(3350mm)
Boom/Stick Option (Hex) 3
A
Shipping Length Of Unit
53.14ft in
J
Max Loading Height
39.01ft in
C
Shipping Height Of Unit
12.92ft in
L
Max Vertical Wall Digging Depth
42.02ft in
M
Max Digging Depth
49.63ft in
Min Digging Reach
0.14ft in
Boom/Stick Option (Hex) 3
Boom 23\'4\" (7100mm)/Arm 26\'3\"(2900mm)
Minimum Swing Radius
308.08in
Dimensions
G
Height To Top Of Cab
11ft in
D
Length Of Track On Ground
17.9ft in
H
Tail Swing Radius
12.47ft in
O
Counterweight Clearance
4.79ft in
Undercarriage Width
13.78ft in
Undercarriage
F
Track Gauge
10.83ft in
N
Shoe Size
35.44in
Ground Pressure
8.4psi
Number Of Shoes Per Side
53
Number Of Bottom Rollers Per Side
9
Number Of Top Rollers Per Side
3
Specifications
Speeds
High
3.4mph
Low
1.9mph
Electrical System
Alternator
28 v, 100 amp
Starter
24V, 8 (6)
Battery
12V, 200AH, 1300CCA
Engine
Starter
8hp
Number Of Cylinders
6
Engine Make
Scania
Engine Model
DC13
Gross Power
380hp
Net Power
373hp
Air Cleaner
Double Elements
Power Measured @
1800rpm
Max Torque
1301.1lb ft
Displacement
775.1cu in
Torque Measured @
1300rpm
Bore
5.2in
Stroke
6.3in
Operational
Def Tank Capacity
18.5gal
Operating Weight
116576lb
Fuel Capacity
181gal
Cooling System Fluid Capacity
13.5gal
Hydraulic System Fluid Capacity
132.1gal
Engine Oil Capacity
11.9gal
Final Drive Fluid Capacity - Each
2.7gal
Swing Drive Fluid Capacity
1.4gal
Hydraulic System Relief Valve Pressure
8.8psi
Hydraulic Tank
103.1gal
Performance
Travel-Normal Mode
4694psi
Travel-Power Mode
4978psi
Swing - Normal Mode
4694psi
Swing-Power Mode
4978psi
Traction Force -Draw Bar Pull
100531lb ft
Maximum Grade
70%
Swing Mechanism
Swing Speed
8.6rpm
Swing Torque
145600lb ft
Weights
Counterweight
24471lb
Buckets
Minimum Bucket Capacity
2.8yd3
Hydraulic
Main Pump Flow Standard
177gal/min
Pilotpump-Gear Design
6.3gal/min
Relief Pressure - Boost
4978psi
Relief Pressure -Normal
4694psi
