Gehl CTL75 Multi Terrain Loader
Units
Dimensions
Dimensions
B
Width Over Tracks
5.81ft in
C
Height To Top Of Cab
7.11ft in
E
Ground Clearance
12.8in
G
Clearance At Max Lift And Dump
7.9ft in
H
Reach At Max Lift And Dump
2.87ft in
Turning Radius From Center - Inc Bucket
90.32in
Length With Bucket
12.28ft in
Length With Out Bucket
9.78ft in
Turning Radius From Center - Machine Rear
65.6in
Undercarriage
D
Length Of Track On Ground
4.91ft in
Number Of Track Rollers Per Side
4
Width Of Track
18in
Ground Pressure
4.3psi
Specifications
Engine
Number Of Cylinders
4
Engine Make
2348
Engine Model
4TNV98T
Gross Power
83hp
Power Measured @
2500rpm
Peak Torque
219lb ft
Torque Measured @
1800rpm
Displacement
202.5cu in
Aspiration
Turbocharged
Operational
Operating Weight
9700.4lb
Cooling System Fluid Capacity
4.4gal
Fuel Capacity
23.9gal
Engine Oil Capacity
2.7gal
Hydraulic System Fluid Capacity
12.9gal
Operating Voltage
12V
Alternator Supplied Amperage
40amps
Max Speed - Low Range
4.7mph
Max Speed - High Range
7.2mph
Loader
Operating Load
2976.3lb
Tipping Angle
5952.5degrees
Bucket Capacity
0.7yd3
Hydraulic
Pump Flow
19.8gal/min
Relief Valve Pressure
2988psi
