Haulotte Compact 3368 RT Scissor Lift
Units
Dimensions
Dimensions
A
Overall Length
10.5in
D
Wheelbase
6ft in
B
Overall Width
5.1ft in
C
Height W/ Rails
8.5ft in
E
Ground Clearance
11in
Height W/O Rails
4.58ft in
Turning Radius
11.6ft in
Gradeability
40%
Platform
F
Max Platform Height
33ft in
I
Deck Extension
47in
Max Working Height
39ft in
Max Platform Weight Capacity
1000lb
Platform Inner Length
96in
Platform Inner Width
57in
Lower Time
51sec
Lift Time
40sec
Specifications
Engine
Engine Make
2349
Gross Power
24.8hp
Fuel Type
Diesel
Operational
Operating Weight
9063lb
Fuel Capacity
8gal
Hydraulic System Fluid Capacity
20gal
Max Speed
3.4mph
Tire Size
26x12-16.5
Tire Fill/Type
Foam
