JLG 330CRT Scissor Lift
Units
Dimensions
Dimensions
A
Overall Length
10.18in
D
Wheelbase
7.55ft in
B
Overall Width
5.75ft in
C
Height W/ Rails
8.11ft in
E
Ground Clearance
9.85in
Height W/O Rails
6.5ft in
Turning Radius
6.99ft in
Platform
F
Max Platform Height
33ft in
I
Deck Extension
35.83in
J
Height Of Rails
3.61ft in
Max Platform Weight Capacity
1000lb
Platform Inner Width
65in
Lift Time
38sec
Platform Inner Length
115in
Lower Time
42sec
Specifications
Engine
Engine Make
2334
Engine Model
750
Gross Power
24.5hp
Fuel Type
Dual
Operational
Operating Weight
9100lb
Fuel Capacity
13gal
Hydraulic System Fluid Capacity
18gal
Max Speed
3.5mph
Tire Size
30.4x10
Tire Fill/Type
Foam
