Hitachi EH4500-2 Rock Truck
Units
Dimensions
Dimensions
A
Overall Length
46.92ft in
B
Overall Width
29.7ft in
C
Overall Height
23.76ft in
D
Wheelbase
20.18ft in
E
Ground Clearance
3.19ft in
F
Dump Height
46.92ft in
G
Dump Ground Clearance
6.47ft in
Dump
H
Dump Angle
58degrees
Load Capacity - Struck
142yd3
Load Capacity - Heaped
208yd3
Rated Payload
620000lb
Lower Time
24sec
Raise Time
22sec
Specifications
Engine
Number Of Cylinders
16
Engine Make
2350
Engine Model
DDEC IV 16V-4000
Net Power
2600hp
Gross Power
2700hp
Power Measured @
1900rpm
Displacement
3967cu in
Aspiration
turbocharged & low temp aftercooled
Operational
Fuel Capacity
999.9gal
Cooling System Fluid Capacity
184.2gal
Engine Oil Capacity
64gal
Diff And Final Drive Fluid Capacity
59gal
Steering System Fluid Capacity
76.9gal
Brake/Hoist System Fluid Capacity
255gal
Hydraulic System Fluid Capacity
331.9gal
Operating Voltage
24V
Alternator Supplied Amperage
260amps
Tire Size
50.90R57 E4 Radial
Transmission
Max Speed
41.6mph
Weights
Empty Weight
436726.9lb
Loaded Weight
1059016.9lb
Weight Distribution Front - Empty
50.2%
Weight Distribution Rear - Empty
49.8%
Weight Distribution Front - Loaded
34%
Weight Distribution Rear - Loaded
67%
