Hitachi EH5000 Rock Truck
Units
Dimensions
Dimensions
A
Overall Length
47.31ft in
B
Overall Width
29.7ft in
C
Overall Height
23.53ft in
D
Wheelbase
20.18ft in
E
Ground Clearance
2.99ft in
F
Dump Height
46.86ft in
G
Dump Ground Clearance
6.11ft in
Dump
H
Dump Angle
58degrees
Load Capacity - Struck
187.8yd3
Load Capacity - Heaped
256.5yd3
Rated Payload
630000lb
Lower Time
24sec
Raise Time
22sec
Specifications
Engine
Number Of Cylinders
16
Engine Make
2350
Engine Model
DDEC IV 16V-4000
Net Power
2600hp
Gross Power
2700hp
Power Measured @
1900rpm
Max Torque
8062lb ft
Displacement
3967cu in
Aspiration
Turbocharged & low temperature aftercooled
Torque Measured @
1500rpm
Operational
Fuel Capacity
1000gal
Cooling System Fluid Capacity
184gal
Engine Oil Capacity
64gal
Steering System Fluid Capacity
77gal
Brake/Hoist System Fluid Capacity
255gal
Hydraulic System Fluid Capacity
332gal
Operating Voltage
24V
Alternator Supplied Amperage
260amps
Tire Size
53/80R63 E4 Radial
Transmission
Max Speed
41.6mph
Weights
Empty Weight
469991lb
Loaded Weight
1164500lb
Weight Distribution Front - Empty
51%
Weight Distribution Rear - Empty
51%
Weight Distribution Front - Loaded
32%
Weight Distribution Rear - Loaded
68%
