Hyundai R130LC-3 Hydraulic Excavator
Dimensions
Boom/Stick Option (Hex) 1
Shipping Length Of Unit
25.33ft in
Shipping Height Of Unit
8.99ft in
Max Cutting Height
26.48ft in
Max Loading Height
19.17ft in
Max Reach Along Ground
25.43ft in
Max Vertical Wall Digging Depth
14.7ft in
Max Digging Depth
16.31ft in
Boom/Stick Option (Hex) 1
Boom - 4600 mm, 15.1 ft in / Arm - 1900 mm, 6.3 ft in
Boom/Stick Option (Hex) 2
Shipping Length Of Unit
25.4ft in
Max Cutting Height
27.14ft in
Shipping Height Of Unit
8.99ft in
Max Loading Height
19.46ft in
Max Reach Along Ground
25.63ft in
Max Vertical Wall Digging Depth
15.03ft in
Max Digging Depth
17.07ft in
Boom/Stick Option (Hex) 2
Boom - 4600 mm, 15.1 ft in / Arm - 2100 mm, 6.11 ft in
Boom/Stick Option (Hex) 3
Shipping Length Of Unit
25.5ft in
Max Cutting Height
27.96ft in
Max Loading Height
19.95ft in
Shipping Height Of Unit
8.99ft in
Max Reach Along Ground
26.91ft in
Max Vertical Wall Digging Depth
16.67ft in
Max Digging Depth
18.38ft in
Boom/Stick Option (Hex) 3
Boom - 4600 mm, 15.1 ft in / Arm - 2500 mm, 8.2 ft in
Boom/Stick Option (Hex) 4
Shipping Length Of Unit
25.5ft in
Shipping Height Of Unit
9.52ft in
Max Cutting Height
28.12ft in
Max Loading Height
20.12ft in
Max Reach Along Ground
27.6ft in
Max Digging Depth
19.2ft in
Boom/Stick Option (Hex) 4
Boom - 4600 mm, 15.1 ft in / Arm - 2750 mm, 9.0 ft in
Max Vertical Wall Dig Depth
17.49ft in
Boom/Stick Option (Hex) 5
Shipping Length Of Unit
25.14ft in
Shipping Height Of Unit
10.21ft in
Max Cutting Height
28.88ft in
Max Loading Height
20.87ft in
Max Reach Along Ground
28.45ft in
Max Digging Depth
20.02ft in
Boom/Stick Option (Hex) 5
Boom - 4100 mm, 13.5 ft in / Arm - 3000 mm, 9.10 ft in
Max Vertical Wall Dig Depth
18.38ft in
Boom/Stick Option (Hex) 6
Max Cutting Height
25ft in
Max Loading Height
17ft in
Shipping Length Of Unit
23.66ft in
Max Reach Along Ground
23.23ft in
Shipping Height Of Unit
8.99ft in
Max Digging Depth
15ft in
Boom/Stick Option (Hex) 6
Boom - 4100 mm, 13.5 ft in / Arm - 1900 mm, 6.3 ft in
Max Vertical Wall Dig Depth
13.23ft in
Dimensions
Ground Clearance
1.45ft in
Height To Top Of Cab
8.99ft in
Width To Outside Of Tracks
7.91ft in
Length Of Track On Ground
12.31ft in
Tail Swing Radius
7.71ft in
Removal Counterweight Clearance
3.07ft in
Undercarriage
Track Gauge
6.57ft in
Shoe Size
23.63in
Ground Pressure
4.99psi
Max Travel Speed
3.24mph
Drawbar Pull
12200lb
Number Of Track Rollers Per Side
7
Number Of Shoes Per Side
46
Number Of Carrier Rollers Per Side
1
Specifications
Engine
Number Of Cylinders
4
Engine Make
Cummins
Engine Model
B3.9 - C
Net Power
102hp
Gross Power
110hp
Power Measured @
2200rpm
Max Torque
332lb ft
Displacement
14584.7cu in
Torque Measured @
1500rpm
Operational
Operating Weight
30423.8lb
Fuel Capacity
58.2gal
Cooling System Fluid Capacity
4.3gal
Hydraulic System Fluid Capacity
63.5gal
Operating Voltage
24V
Engine Oil Capacity
3gal
Swing Drive Fluid Capacity
0.6gal
Alternator Supplied Amperage
50amps
Hydraulic Pump Flow Capacity
68.7gal/min
Swing Mechanism
Swing Speed
13.6rpm
