JCB 190 Skid Steer Loader
Units
Dimensions
Dimensions
A
Length With Bucket
11.49ft in
B
Width Over Tires
5.55ft in
C
Height To Top Of Cab
6.61ft in
D
Wheelbase
3.7ft in
F
Length W/O Bucket
8.19ft in
G
Clearance At Max Lift And Dump
7.95ft in
H
Reach At Max Lift And Dump
24.93in
Turning Radius From Center - Machine Rear
65.52in
Turning Radius From Center - Inc Bucket
86.58in
Specifications
Engine
Number Of Cylinders
4
Engine Model
1104C-44
Gross Power
80hp
Net Power
70hp
Power Measured @
2200rpm
Aspiration
Natural aspirated
Displacement
244.1cu in
Operational
Operational Weight
7717lb
Fuel Capacity
28.2gal
Cooling System Fluid Capacity
3.9gal
Engine Oil Fluid Capacity
2.3gal
Hydraulic System Fluid Capacity
9.2gal
Max Speed
6.9mph
Chain Box Fluid Capacity - Each Side
3.3gal
Tire Size
12 x 16.5 - 10 pr
Operating Voltage
12V
Alternator Supplied Amperage
72amps
Loader
Breakout Force
4387.2lb
Operating Load Rating
1985lb
Tipping Angle
3969degrees
Bucket Capacity
0.7yd3
Hydraulic
Pump Type
Hydrostatic drive pumps
Pump Flow Capacity
20gal/min
Relief Valve Pressure
2682psi
