JCB 250 Skid Steer Loader
Units
Dimensions
Dimensions
E
Ground Clearance
9.85in
D
Wheelbase
4.11ft in
Dig Depth
393.71in
Dump Angle
42degrees
Dump Height
7.55ft in
Loadover Height
9514.44ft in
Max. Reach @ Full Height
3.29ft in
Overall Height
6.89ft in
Overall Length
152.76in
Pin Height
10.5ft in
Quick Hitch Turning Radius
4.93ft in
Reach @ Ground Level
3.61ft in
Rear Chassis Turning Radius
5.78ft in
Rollback - Ground Level
30degrees
Angle Of Departure
29degrees
Width Over Tyres
70.87in
Bucket Corner Turning Radius
7.55ft in
Specifications
Tyres
Standard
12 x 16.5 - 10 PR Xtra Wall Off Road
Engine
Emissions Certification
EPA-T4F (EU St3B)
Fuel
Diesel
Starter Motor
4.2 KW
Battery
12 V
Hydraulically Driven Cooling Fan
Yes
Engine Oil Service Interval
500 hours
Engine Model
EcoMAX TCAE-55
Gross Power
73.8hp
Cooling System
Diesel
Power Measured @
2400rpm
Max Torque
295.1lb ft
Torque Measured @
1200rpm
Aspiration
Turbo
Displacement
4399cu in
Alternator
95amps
Capacities
Fuel Tank
27.3gal
Hydraulic System
14.6gal
Engine Oil
4gal
Engine Coolant
5.9gal
Operational
Operational Weight
8214.5lb
Transmission
Model
Two Speed
Travel Speed
12mph
Loader
Loader Lift Capacity With Bucket
5884.2lb
Breakout Force
6543.4lb
Tipping Angle
5055.2degrees
Bucket Capacity
0.6yd3
Bucket Width
78.4in
Hydraulic
Pump Flow Capacity
23.8gal/min
Relief Valve Pressure
483.8psi
