Thomas 320 Skid Steer Loader
Units
Dimensions
Dimensions
A
Length With Bucket
12.17ft in
B
Width Over Tires
5.9ft in
E
Ground Clearance
19.2in
C
Height To Top Of Cab
7.01ft in
D
Wheelbase
4.07ft in
F
Length W/O Bucket
9.8ft in
G
Clearance At Max Lift And Dump
8.07ft in
H
Reach At Max Lift And Dump
21.5in
Turning Radius From Center - Machine Rear
34.91in
Turning Radius From Center - Inc Bucket
42.01in
Specifications
Engine
Engine Make
2334
Engine Model
V3300T
Gross Power
87.5hp
Net Power
83hp
Power Measured @
2750rpm
Displacement
203cu in
Operational
Operational Weight
8175lb
Fuel Capacity
28.8gal
Max Speed
12.4mph
Hydraulic System Fluid Capacity
24gal
Tire Size
12.00x16.5
Alternator Supplied Amperage
60amps
Loader
Breakout Force
7000lb
Operating Load Rating
2525lb
Tipping Angle
5000degrees
Hydraulic
Pump Flow Capacity
21gal/min
Relief Valve Pressure
3000psi
