Kobelco SK480LC Hydraulic Excavator
Units
Dimensions
Boom/Stick Option (Hex) 1
A
Shipping Length Of Unit
39.31ft in
C
Shipping Height Of Unit
11.52ft in
I
Max Cutting Height
35.93ft in
J
Max Loading Height
24.91ft in
K
Max Reach Along Ground
38.85ft in
L
Max Vertical Wall Digging Depth
22.81ft in
M
Max Digging Depth
25.6ft in
Boom/Stick Option (Hex) 1
Stick w/ arm 11\'4\" (3450mm)
Boom/Stick Option (Hex) 2
I
Max Cutting Height
36.39ft in
J
Max Loading Height
25.43ft in
K
Max Reach Along Ground
40.62ft in
L
Max Vertical Wall Digging Depth
24.38ft in
M
Max Digging Depth
27.53ft in
Boom/Stick Option (Hex) 2
Stick w/ arm 13\\\'3\\\" (4040mm)
Boom/Stick Option (Hex) 3
I
Max Cutting Height
38.42ft in
J
Max Loading Height
27.27ft in
K
Max Reach Along Ground
43.57ft in
L
Max Vertical Wall Digging Depth
27.56ft in
M
Max Digging Depth
30.35ft in
Boom/Stick Option (Hex) 3
Stick w/ arm 16\'1\" (4900mm)
Dimensions
E
Ground Clearance
1.69ft in
G
Height To Top Of Cab
10.9ft in
B
Width To Outside Of Tracks
11.98ft in
D
Length Of Track On Ground
14.44ft in
H
Tail Swing Radius
11.98ft in
Removal Counterweight Clearance
4.43ft in
Undercarriage
F
Track Gauge
9.03ft in
N
Shoe Size
35.44in
Drawbar Pull
90598lb
Ground Pressure
7.33psi
Max Travel Speed
3.48mph
Specifications
Engine
Engine Make
2251
Engine Model
6D24-TLA2B
Net Power
315hp
Power Measured @
2000rpm
Displacement
729cu in
Operational
Operating Weight
108026.6lb
Fuel Capacity
171.8gal
Cooling System Fluid Capacity
12.7gal
Hydraulic System Fluid Capacity
174.4gal
Engine Oil Capacity
13gal
Hydraulic System Relief Valve Pressure
3700psi
Hydraulic Pump Flow Capacity
203.5gal/min
Swing Mechanism
Swing Torque
118010lb ft
Swing Speed
9rpm
Buckets
Reference Bucket Capacity
2.4yd3
Minimum Bucket Capacity
1.5yd3
Maximum Bucket Capacity
4yd3
