New Holland LT190.B Multi Terrain Loader
Units
Dimensions
Dimensions
B
Width Over Tracks
6.7ft in
C
Height To Top Of Cab
6.64ft in
E
Ground Clearance
8.27in
G
Clearance At Max Lift And Dump
8.49ft in
H
Reach At Max Lift And Dump
2.66ft in
Length With Bucket
12.14ft in
Turning Radius From Center - Inc Bucket
80.71in
Undercarriage
D
Length Of Track On Ground
5.39ft in
I
Track Gauge
5.42ft in
Number Of Track Rollers Per Side
4
Width Of Track
15.75in
Ground Pressure
4.6psi
Specifications
Engine
Engine Make
2249
Engine Model
445M2
Gross Power
81hp
Net Power
74hp
Peak Torque
236lb ft
Displacement
274cu in
Aspiration
Natural
Operational
Operating Weight
9295lb
Cooling System Fluid Capacity
4.5gal
Fuel Capacity
21.5gal
Engine Oil Capacity
3.2gal
Hydraulic System Fluid Capacity
15gal
Operating Voltage
12V
Alternator Supplied Amperage
95amps
Max Speed - Low Range
5.1mph
Max Speed - High Range
8mph
Loader
Breakout Force
7670lb
Operating Load
2900lb
Tipping Angle
8286degrees
Hydraulic
Pump Type
Gear Pump
Pump Flow
21.9gal/min
Relief Valve Pressure
3000psi
