Volvo EC15 Mini Excavator
Units
Dimensions
Boom/Stick Option (Hex) 1
A
Shipping Length Of Unit
11.98ft in
I
Max Cutting Height
11.19ft in
C
Shipping Height Of Unit
7.39ft in
J
Max Loading Height
8.14ft in
K
Max Reach Along Ground
4.93ft in
L
Max Vertical Wall Digging Depth
4.93ft in
M
Max Digging Depth
7.22ft in
Boom/Stick Option (Hex) 1
Boom 5'9" (1750mm)/Stick 2'11" (900mm)
Boom/Stick Option (Hex) 2
I
Max Cutting Height
11.65ft in
A
Shipping Length Of Unit
11.98ft in
J
Max Loading Height
8.6ft in
C
Shipping Height Of Unit
7.39ft in
K
Max Reach Along Ground
5.71ft in
L
Max Vertical Wall Digging Depth
5.71ft in
M
Max Digging Depth
8.04ft in
Boom/Stick Option (Hex) 2
Boom 5'9" (1750mm)/Stick 3'9" (1150mm)
Dimensions
B
Width To Outside Of Tracks
3.22ft in
D
Length Of Track On Ground
3.43ft in
E
Ground Clearance
0.69ft in
G
Height To Top Of Cab
7.39ft in
H
Tail Swing Radius
3.81ft in
Removal Counterweight Clearance
1.48ft in
Undercarriage
N
Shoe Size
9.06in
F
Track Gauge
2.5ft in
Max Travel Speed
1.25mph
Ground Pressure
4.41psi
Specifications
Engine
Number Of Cylinders
3
Engine Make
2251
Engine Model
L3E
Gross Power
18.8hp
Net Power
15.2hp
Power Measured @
2200rpm
Displacement
58cu in
Max Torque
39.9lb ft
Torque Measured @
1850rpm
Operational
Operating Weight
3450.3lb
Fuel Capacity
5.6gal
Cooling System Fluid Capacity
1.2gal
Hydraulic System Fluid Capacity
6.1gal
Engine Oil Capacity
1gal
Operating Voltage
12V
Alternator Supplied Amperage
40amps
Hydraulic System Relief Valve Pressure
2465psi
Hydraulic Pump Flow Capacity
8.5gal/min
Swing Mechanism
Swing Speed
9rpm
Buckets
Reference Bucket Capacity
0.1yd3
Minimum Bucket Capacity
0.1yd3
Maximum Bucket Capacity
0.1yd3
