Caterpillar 267B Multi Terrain Loader
Units
Dimensions
Dimensions
B
Width Over Tracks
6.23ft in
C
Height To Top Of Cab
6.81ft in
E
Ground Clearance
14in
G
Clearance At Max Lift And Dump
7.71ft in
H
Reach At Max Lift And Dump
2.22ft in
Hinge Pin Height, Maximum Height
121.7in
Length - Track On Ground
81in
Length - With Bucket On Ground
145in
Length - Without Bucket
115in
Length With Bucket
12.09ft in
Bucket Pin Height - Maximum Lift
10.17ft in
Clearance At Maximum Lift And Dump
93in
Dump Angle
40degrees
Height - Top Of Cab
6.84ft in
Turn Radius From Center - Rear
60.8in
Turning Radius From Center - Machine Rear
98.9in
Vehicle Width
75in
Bucket Pin Height - Carry Position
10in
Length With Out Bucket
9.59ft in
Maximum Overall Height
158in
Maximum Reach - With Arms Parallel
57.3in
Overall Height
13.21ft in
Overall Length - Track
98in
Overall Track Length
8.19ft in
Reach At Maximum Lift/Dump
27in
Turn Radius From Center - Bucket
98.9in
Turn Radius From Center - Coupler
63.1in
Undercarriage
D
Length Of Track On Ground
6.71ft in
Ground Contact Area
2898.51in2
Ground Pressure
3.15psi
Specifications
Engine
Engine Model
Cat 3044C DIT
Gross Power
73hp
Net Power
70hp
Displacement
201cu in
Bore
3.7in
Stroke
4.7in
Gross Power - Sae J1995
73hp
Engine Model
Cat 3044C DIT
Engine Power - Iso 14396
71hp
Net Power - Eec 80/1269
71hp
Net Power - Iso 9249 Eec
71hp
Net Power - Sae 1349
70hp
Operational
Operating Weight
9369.7lb
Cooling System Fluid Capacity
2.7gal
Fuel Capacity
25.1gal
Hydraulic System Fluid Capacity
13.8gal
Operating Voltage
12V
Alternator Supplied Amperage
90amps
Performance
Speed - Forward Maximum
7mph
Speed - Reverse Maximum
7mph
Power Train
Travel Speed Forward
7mph
Travel Speed Reverse
7mph
Loader
Breakout Force
5482.9lb
Tipping Load
5798.2lb
Operating Load
2899.1lb
Weights
Operating Weight
9371lb
Hydraulic
Pump Type
Standard
Pump Flow
22gal/min
Relief Valve Pressure
3335.9psi
Hydraulic System
Hydraulic Power
42.8hp
Loader Hydraulic Pressure
3335 psi
Loader Hydraulic Flow
22 gal/min
Hydraulic Flow
Standard
Operating Specifications
Rated Operating Capacities - 50% Tipping Load
2900lb
Rated Operating Capacities - 35% Tipping Load
2030lb
Ground Contact Area
2898in2
Ground Pressure
3.1 psi
Tipping Load
5800lb
Breakout Force - Tilt Cylinder
5484lb
Service Refill Capacities
Cooling System
2.6gal
Fuel Tank
25.1gal
Hydraulic Tank
9.2gal
Engine Crankcase
2.6gal
Hydraulic System
13.7gal
Cab
Rops
SAE J1040 MAY94, ISO 3471:1994
Fops
SAE J/ISO 3449 APR98, ISO 3449:1992 Level I
Fops Level Ii
SAE J/ISO 3449 APR98 Level II, ISO 3449:1992 Level II
